Garden Bed Irrigation Kit - Large

This system connects easily to any standard outdoor hose faucet.

Step 1: The Header (Faucet Assembly)
If you purchased the kit With Timer, attach the Timer to the faucet first. Next, simply screw on the Filter, then the Pressure Regulator, and finally the Easy Loc Female Hose Start. This entire assembly is commonly referred to as the "Header."

Step 2: Lay the Mainline
Run the 3/4" Mainline Tubing from the Header to the perimeter of your garden beds. Use the Easy Loc Tee or Coupler to split or extend the line if needed. Close the end with a simple Easy Loc End Cap.

Step 3: Connect the Beds
Use the included Punch N' Cut Tool to easily punch a hole in the Mainline. Insert a 1/4" Transfer Barb and attach the 1/4" Micro Tubing to run up into the raised bed.

Step 4: Layout the Dripline
Inside the bed, connect the 1/4" Soaker Dripline to the Micro Tubing. You can run the dripline in rows or snake it around your plants (typically 12" apart). The line is flexible, so your rows do not have to be perfectly straight. Secure it with the Hold Down Stakes.

For detailed assembly instructions click here, or for more detailed plans see the downloads section below.

System Specifications

What's In The Box

We've included every component needed for a standard installation. Click any item to view details or purchase spares.

Is this kit easy to install?
Yes! This kit is designed specifically for simple DIY installation. It requires no glue or special tools (other than the included punch). Most users can install it in under an hour.

Can I connect this to a timer?
Absolutely. You can attach any standard hose faucet timer directly to the faucet before the filter assembly. For this high-capacity kit, we recommend a High Flow Timer to ensure adequate water volume.

Does this work for flowers and vegetables?
Yes. The 1/4" Soaker Dripline is perfect for rows of vegetables, flower beds, and dense planting areas. It provides gentle, uniform moisture ideal for root health.

Is it expandable?
While this kit is designed as a complete system for up to 18 beds, you can customize the layout. However, since this kit already maxes out the typical capacity of a single hose faucet zone (approx. 600 GPH), we do not recommend expanding it significantly further without adding another zone or checking your flow rate.
