The Galcon Bluetooth High Flow Timer (1" Valve) brings professional-grade watering capacity straight to your smartphone. Designed specifically for hard-plumbed, heavy-duty applications, this water-resistant timer features a robust 1" built-in hydraulic latching solenoid valve capable of handling massive flow rates up to 32 gallons per minute (GPM). This makes it ideal for running extensive drip irrigation networks, large sprinkler zones, roof gardens, and expansive flowerbeds. Because this unit is meant to be plumbed directly into your mainline using 1" PVC fittings or poly adapters, it does not include garden hose thread adapters.
Programming is exceptionally versatile and user-friendly. Set weekly, daily, or cyclical watering schedules either directly on the removable LCD controller or wirelessly from 14 to 90 feet away using the Bluetooth smartphone app. Built to withstand challenging outdoor environments, it includes a manual override feature, a low battery indicator, and a heavy-duty housing. For the best longevity, we highly recommend installing a water filter upstream to keep the internal valve free of debris.
Detailed specifications for system planning and compatibility.
| Specification | Details |
|---|---|
| Inlet / Outlet | 1" Female Pipe Thread (FPT) *Adapters NOT Included |
| Flow Range | 0.5 to 32 Gallons Per Minute (GPM) |
| Operating Pressure | 10 to 145 PSI |
| Start Times | Up to 4 per day (Daily, or up to every 30 days) |
| Watering Duration | 1 minute to 12 hours |
| Bluetooth Range | 14 to 90 feet (depending on surroundings) |
| Power Source | One 9-Volt Industrial Alkaline Battery (Not Included) |
| Mounting Requirement | Must be placed in a strictly horizontal position |
| MPN | 7101BT (1" Version) |
| Warranty | 2 Years |
Follow these steps to safely install and program your 1" high-flow timer.
Step 1: Install the Battery
Remove the LCD controller faceplate and insert one fresh 9-volt industrial alkaline battery. Ensure the connection is secure and replace the faceplate to maintain water resistance.
Step 2: Connect to the Mainline
Using thread seal tape, wrap the threads of your 1" Male Pipe Thread (MPT) PVC or poly adapters. Thread them into the timer's inlet and outlet, ensuring the entire assembly is mounted in a strictly horizontal position for proper valve operation.
Step 3: Pair via Bluetooth
Download the Galcon companion app on your smartphone. Ensure Bluetooth is enabled, open the app, and follow the prompts to pair the timer to your device.
Step 4: Program Your Schedule
Use the app (or the physical LCD buttons on the removable faceplate) to set your desired start times, run durations, and watering frequencies. Perform a manual test to verify water flow.
Does this timer include garden hose adapters?
No, this 1" model features female pipe thread (FPT) connections and does not include hose adapters. You will need 1" MPT fittings to connect it to your PVC or poly mainline.
If you are looking for a high-flow timer that connects directly to a standard garden hose spigot right out of the box, consider the 3/4" version of the Galcon High Flow Timer.
What is the maximum flow rate for this 1" timer?
This high-capacity timer can handle an impressive flow rate of up to 32 gallons per minute (GPM), making it ideal for running extensive drip irrigation networks or large sprinkler zones.
Because of this massive flow potential, it is perfectly suited for light commercial applications, large estates, and multi-bed nursery setups.
Can I install this valve vertically?
No, this timer must be installed in a strictly horizontal position for the internal hydraulic latching solenoid to operate correctly and prevent leaks.
Installing the valve body vertically can cause the internal mechanisms to fail over time, voiding the warranty and leading to improper water shut-off.
How far away can I program this using my phone?
You can comfortably program the timer from 14 to 90 feet away using the Bluetooth app, depending on physical obstructions like walls or heavy foliage.
This allows you to easily adjust schedules from your porch or walkway without having to open an underground valve box or kneel in the dirt.
Please note the following critical installation requirements:
Ensure your heavy-duty irrigation manifold runs perfectly with these recommended add-ons:
