The Galcon 6101 DC Single Station Timer offers a solid, bargain-friendly entry into commercial-grade irrigation automation. Designed to manage a single zone without the need for a hardwired AC power supply, this battery-operated timer features a sturdy, weather-resistant housing that makes it ideal for remote gardens, small landscapes, and off-grid locations. When paired with a compatible Galcon DC 2-wire valve, it provides incredibly reliable automation that is simple to install and program.
Despite its simple single-station design, the Galcon 6101 does not compromise on functionality. It features an intuitive interface that allows for up to four start times per day with watering durations ranging from one minute up to twelve hours. Fully equipped for daily or monthly scheduling, master valve connectivity, and rain sensor capability, this DC timer gives you professional-level control in an easily accessible, standalone unit.
Detailed specifications for system planning.
| Specification | Details |
|---|---|
| Controller Type | DC Battery Operated, Single-Station |
| Stations | 1 Station (Valve sold separately) |
| Power Source | One 9-Volt Industrial Alkaline Battery (Not Included) |
| Start Times | Up to 4 start times per day |
| Run Time Duration | 1 minute to 12 hours |
| Programming Options | Daily and Monthly |
| Compatible Valves | Galcon DC, 2-wire valves |
| Mounting | Outdoor Wall or Post Mount |
| Warranty | 2-Year Manufacturer Warranty |
| MPN | GAJ1S0002P0 |
Get your single-station battery controller running smoothly.
Step 1: Mount the Controller
Select an appropriate outdoor wall or post location. Use mounting hardware to securely attach the weather-resistant housing in an easily accessible spot above ground.
Step 2: Install Battery
Open the battery compartment and install one fresh 9-volt industrial alkaline battery to power the unit.
Step 3: Wire the Valve
Run direct burial wire from the controller to your valve location. Connect the wires from your Galcon DC 2-wire latching solenoid into the designated station terminals inside the controller housing.
Step 4: Program Your Zone
Use the interface to set the current time. Then, program your desired watering durations (from 1 minute up to 12 hours) and schedule up to 4 start times per day.
Does the Galcon 6101 require an electrical outlet?
No, the Galcon 6101 is a DC-powered timer that operates entirely on a single 9-volt alkaline battery. This makes it perfect for remote sites and areas without AC power access.
Because it is battery operated, it must be paired specifically with a DC latching solenoid, not standard 24V AC valves.
Which valves work with the Galcon 6101 controller?
The Galcon 6101 controller is designed specifically to operate Galcon DC 2-wire latching solenoids. It will not work with standard 24V AC valves from other manufacturers, so ensure you have the correct DC components.
This DC system is what allows the unit to run reliably off of battery power for an entire season.
Is the Galcon 6101 timer waterproof?
The Galcon 6101 features a sturdy, weather-resistant housing designed for outdoor mounting. While highly protected against rain and typical yard moisture, it is not fully submersible and should not be installed underwater in flooded valve boxes.
For completely submersible applications inside a flooded box, look for fully potted IP68-rated controllers instead.
How should I prepare my Galcon 6101 for spring watering?
Prepare the Galcon 6101 for spring by installing a fresh 9-volt alkaline battery, checking your valve wire connections, and programming a conservative watering schedule that you can slowly increase as the weather continues to warm.
If you experience heavy spring rains, you can utilize the rain sensor capability or use manual overrides to prevent unnecessary watering.
Please note the requirements for this commercial timer:
