Aqua-Traxx Azul is the latest generation of tape technology from Toro. It features an innovative emitter design that protects the labyrinth from debris and maximizes clog resistance making it the perfect method of irrigating row crops and raised beds.
Use with
Features:
- Low-cost, effective watering for row crops and raised beds
- Superb watering efficiency and uniformity
- Ideal for above ground, mulched or buried applications
- Great for low-pressure systems, works down to 4 PSI
- Requires only 120 mesh filtration
- Use with drip tape fittings
- Low operating pressures, see chart below
- Typically lasts up to 7 years if covered, and 2-5 years on surface
Specifications:
- Warranty: 6 months
- Pressure Range: 4-12 PSI
- Filtration Requirements: Minimum 120 mesh recommended
- Installation: Blue Stripe Up
| Part # | Emitter Spacing | Flow | Max Row Length | Flow per 100' @ 8 PSI | Max Row Length w/ | Roll Size | |
|---|---|---|---|---|---|---|---|
| GPH | GPM | ||||||
| TAZ1508LSR | 8" OC | Low | 700 ft. | 20 GPH | .34 GPM | 380 ft. | 1,000 ft. |
| TAZ1508HSR | 8" OC | High | 460 ft. | 40 GPH | .67 GPM | 200 ft. | 1,000 ft. |
| TAZ1508L | 8" OC | Low | 700 ft. | 20 GPH | .34 GPM | 380 ft. | 4,000 ft. |
| TAZ1508H | 8" OC | High | 460 ft. | 40 GPH | .67 GPM | 200 ft. | 4,000 ft. |
| TAZ1512L | 12" OC | Low | 900 ft. | 13 GPH | .22 GPM | 550 ft. | 4,000 ft. |
| TAZ1512H | 12" OC | High | 600 ft. | 27 GPH | .45 GPM | 280 ft. | 4,000 ft. |
