The Hydro-Rain BL-406-007 3/4" Blu-Lock Elbow is designed to change the direction of your Blu-Lock Tubing by 90 degrees instantly. Using a revolutionary "push-and-go" retention system, this fitting eliminates the messy primer, toxic glues, and long drying times associated with traditional PVC installation.
Perfect for high-pressure sprinkler systems, this unit features a stainless steel retainer ring that grips the pipe securely while an EPDM seal ensures a leak-free joint. It is widely considered one of the most efficient irrigation fittings on the market, allowing installers to work wet or dry and reducing installation time by up to 80%.
Engineering details for your system design.
| Specification | Details |
|---|---|
| Product Type | 90° Elbow |
| Connection Size | 3/4" x 3/4" Push-Fit |
| Compatibility | 3/4" Blu-Lock Pipe (HDPE) ONLY |
| Pressure Rating | Up to 100 PSI (Constant Pressure) |
| Material | ABS Body, 304 Stainless Steel Teeth, EPDM Seal |
| MPN | BL-406-007 |
| Common Brand Names | Hydro-Rain, Orbit, Blu-Lock |
Installation is tool-free (except for cutting the pipe).
Step 1: Cut the Pipe
Ensure a clean, square cut on your 3/4" Blu-Lock tubing. Avoid using hacksaws that leave burrs; a sharp pipe cutter is recommended.
Step 2: Mark Insertion Depth (Optional)
For precision, mark the pipe approximately 1 inch from the end to ensure you push it in far enough.
Step 3: Push to Connect
Insert the pipe firmly into the elbow until it hits the internal stop. The steel teeth will grab the pipe instantly.
Step 4: Check the Seal
Give a gentle tug to ensure the teeth have engaged. The connection is now ready for water pressure immediately.
Crucial information for a leak-free system:
Everything you need for a fast, modern sprinkler installation:
